Festo 175054. Throttle valve GRLO-M5-QS-3-LF-C
€20.91
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-175054
Manufacturer Nr.
GRLO-M5-QS-3-LF-C
Throttle valve
Frequently Bought Together
-
This Item:
€20.91Excl. 19% VAT , excl. Shipping Cost
-
Festo 197576. One-way flow control valve GRLA-M5-QS-3-RS-D
€14.65Excl. 19% VAT , excl. Shipping Cost
-
Festo 152611. One-way flow control valve GR-M5X2-B
€61.28Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | Flow control function |
| Pneumatic connection, port 1 | M5 |
| Pneumatic connection, port 2 | QS-3 |
| Adjustment component | Slotted head screw |
| Type of mounting | Screw-in |
| Standard nominal flow rate in flow control direction | 40 l/min |
| Operating pressure | 0 bar ... 10 bar |
| Ambient temperature | -10 °C ... 60 °C |
| Mounting position | optional |
| Symbol | 00991454 |
| Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi) | 80 l/min |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -10 °C ... 60 °C |
| Max. tightening torque | 1.5 Nm |
| Product weight | 9 g |
| Material screwed plug | Brass |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material release ring | POM |
| Material adjusting screw | Brass |
| Material swivel fitting | Die-cast zinc |
| Manufacturer Nr. | GRLO-M5-QS-3-LF-C |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568037727 |
| Weight | 0.013000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
