Festo 175042. Throttle valve GRLO-M3-QS-3

Name: Festo 175042. Throttle valve GRLO-M3-QS-3
Brand: Festo
SKU: FES-175042
Price: 22.81 EUR
Availability: InStock

€22.81

Excl. 19% VAT , excl. Shipping Cost

Article

FES-175042

Manufacturer Nr.

GRLO-M3-QS-3

Throttle valve

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 175042. Throttle valve GRLO-M3-QS-3
€22.81
Excl. 19% VAT , excl. Shipping Cost
Festo 193156. One-way flow control valve GRLZ-1/8-QS-3-D
€14.00
Excl. 19% VAT , excl. Shipping Cost
Festo 151178. One-way flow control valve GRLA-3/8-B
€37.28
Excl. 19% VAT , excl. Shipping Cost

Total price

Valve function	Flow control function
Pneumatic connection, port 1	M3
Pneumatic connection, port 2	QS-3
Adjustment component	Slotted head screw
Type of mounting	Screw-in
Standard nominal flow rate in flow control direction	41 l/min
Operating pressure	0 bar ... 10 bar
Ambient temperature	-10 °C ... 60 °C
Mounting position	optional
Symbol	00991454
Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi)	95 l/min
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Media temperature	-10 °C ... 60 °C
Max. tightening torque	0.3 Nm
Product weight	7 g
Material screwed plug	Brass
Note on materials	RoHS-compliant
Material seals	NBR
Material release ring	POM
Material adjusting screw	Brass
Material swivel fitting	Die-cast zinc

More Information
Manufacturer Nr.	GRLO-M3-QS-3
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568037666
Weight	0.008200
HS-Code	84812090
Article authenticity	Original product
Condition of article	New
