Festo 151181. Throttle valve GRLO-M5-B

Name: Festo 151181. Throttle valve GRLO-M5-B
Brand: Festo
SKU: FES-151181
Price: 21.23 EUR
Availability: InStock

€21.23

Excl. 19% VAT , excl. Shipping Cost

Article

FES-151181

Manufacturer Nr.

GRLO-M5-B

Throttle valve

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 151181. Throttle valve GRLO-M5-B
€21.23
Excl. 19% VAT , excl. Shipping Cost
Festo 175039. Throttle valve GRLO-M3
€22.40
Excl. 19% VAT , excl. Shipping Cost
Festo 151192. One-way flow control valve GRLZ-1/8-RS-B
€26.38
Excl. 19% VAT , excl. Shipping Cost

Total price

Valve function	Flow control function
Pneumatic connection, port 1	M5
Pneumatic connection, port 2	M5
Adjustment component	Slotted head screw
Type of mounting	Screw-in
Standard nominal flow rate in flow control direction	95 l/min
Operating pressure	0 bar ... 10 bar
Ambient temperature	-10 °C ... 60 °C
Nominal size	2 mm
Mounting position	optional
Symbol	00991454
Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi)	169 l/min
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Media temperature	-10 °C ... 60 °C
Max. tightening torque	1.5 Nm
Product weight	11 g
Material screwed plug	Brass Nickel-plated
Note on materials	RoHS-compliant
Material seals	NBR
Material adjusting screw	Brass
Material swivel fitting	Die-cast zinc

More Information
Manufacturer Nr.	GRLO-M5-B
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568010614
Weight	0.014000
HS-Code	84812090
Article authenticity	Original product
Condition of article	New
