Festo 175380. Plug FBS-M12-5GS-PG9
Manufacturer Nr.
FBS-M12-5GS-PG9
Frequently Bought Together
Based on standard EN 61076-2-101
EN 61984 Type of mounting Via threaded sleeve Mounting position optional Product weight 23.5 g Electrical connection 5-pin
Type A
M12x1
Straight plug connector/screw terminal Operational voltage range DC 60 V Operational voltage range AC 60 V Current rating at 40° C 4 A Immunity to surge 1.5 kV Cable fitting Pg 9 Permissible cable diameter 6 mm ... 8 mm Connection cross section 0.75 mm² Degree of protection IP67 Ambient temperature -40 °C ... 85 °C CE mark (see declaration of conformity) To EU Low Voltage Directive CE marking (see declaration of conformity) To UK regulations for electrical equipment LABS (PWIS) conformity VDMA24364-B2-L Note on materials RoHS-compliant Pollution degree 3 Corrosion resistance class CRC 1 - Low corrosion stress Material housing PA-reinforced Housing colour Black Material union nut Die-cast zinc
Nickel-plated Material electrical contact Brass
Nickel-plated and gold-plated
More Information
Manufacturer Nr.
FBS-M12-5GS-PG9
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568075026
Weight
0.025000
HS-Code
85366990
Article authenticity
Original product
Condition of article
New
