Festo 185865. Vacuum generator CPV10-M1H-VI70-2GLS-M7
Manufacturer Nr.
CPV10-M1H-VI70-2GLS-M7
Frequently Bought Together
Nominal size, Laval nozzle 0.7 mm Mounting position optional Ejector characteristic High vacuum Symbol 00991561 Operating pressure 2 bar ... 10 bar Max. vacuum 85 % Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature 0 °C ... 50 °C Ambient temperature 0 °C ... 50 °C Product weight 25 g Electrical connection Plugs Type of mounting With through-hole Pneumatic connection, port 1 Sub-base Pneumatic connection, port 3 Sub-base Vacuum connection M7 Note on materials RoHS-compliant Material housing Die-cast aluminium
More Information
Manufacturer Nr.
CPV10-M1H-VI70-2GLS-M7
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568146108
Weight
0.080000
HS-Code
84141089
Article authenticity
Original product
Condition of article
New
