Festo 185874. Vacuum generator CPV18-M1H-V140-1/4
Manufacturer Nr.
CPV18-M1H-V140-1/4
Frequently Bought Together
Nominal size, Laval nozzle 1.4 mm Mounting position optional Ejector characteristic High vacuum Symbol 00991560 Operating pressure 3 bar ... 8 bar Max. vacuum 85 % Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature 0 °C ... 50 °C Ambient temperature 0 °C ... 50 °C Product weight 227 g Electrical connection Plugs Type of mounting With through-hole Pneumatic connection, port 1 Sub-base Pneumatic connection, port 3 Sub-base Vacuum connection G1/4 Note on materials RoHS-compliant Material housing Die-cast aluminium
More Information
Manufacturer Nr.
CPV18-M1H-V140-1/4
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568146139
Weight
0.240000
HS-Code
84141089
Article authenticity
Original product
Condition of article
New
