Festo 197570. Parallel gripper HGPM-12-EZ-G9
Manufacturer Nr.
HGPM-12-EZ-G9
Frequently Bought Together
Size 12 Stroke per gripper jaws 3 mm Max. replacement accuracy 0.2 mm Repetition accuracy, gripper 0.05 mm Number of gripper jaws 2 Drive system Pneumatic Mode of operation Single-acting
Closed Gripper function Parallel Gripper force back-up None Design Wedge-shaped drive Position detection Without Symbol 00991898 Gripping force per gripper jaw, closing, 0.6 MPa (6 bar, 87 psi) 35 N Operating pressure 4 bar ... 8 bar Max. operating frequency of gripper 4 Hz Min. opening time at 0.6 MPa (6 bar, 87 psi) 3 ms Min. closing time at 0.6 MPa (6 bar, 87 psi) 8.3 ms Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Ambient temperature 5 °C ... 60 °C Gripper force per gripper jaw, opening, 0.6 MPa (6 bar, 87 psi) 17.5 N Max. force on gripper jaw Fz static 30 N Max. torque at gripper Mx static 0.5 Nm Max. torque at gripper My static 0.5 Nm Max. torque at gripper Mz static 0.5 Nm Product weight 62 g Type of mounting Via female thread Pneumatic connection M3 Note on materials RoHS-compliant Material cover cap POM Material housing Anodised wrought aluminium alloy Material gripper jaws High-alloy steel
More Information
Manufacturer Nr.
HGPM-12-EZ-G9
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568160678
Weight
0.155000
HS-Code
84798997
Article authenticity
Original product
Condition of article
New
