Festo 197560. Parallel gripper HGPM-08-EO-G8
Manufacturer Nr.
HGPM-08-EO-G8
Frequently Bought Together
Size 8 Stroke per gripper jaws 2 mm Max. replacement accuracy 0.2 mm Rotationally symmetrical 0.15 mm Repetition accuracy, gripper 0.05 mm Number of gripper jaws 2 Drive system Pneumatic Mode of operation Single-acting
Open Gripper function Parallel Gripper force back-up None Design Wedge-shaped drive Position detection Without Symbol 00991897 Gripping force per gripper jaw, opening, 0.6 MPa (6 bar, 87 psi) 16 N Operating pressure 4 bar ... 8 bar Max. operating frequency of gripper 4 Hz Min. opening time at 0.6 MPa (6 bar, 87 psi) 4.9 ms Min. closing time at 0.6 MPa (6 bar, 87 psi) 2.3 ms Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Ambient temperature 5 °C ... 60 °C Gripper force per gripper jaw, closing, 0.6 MPa (6 bar, 87 psi) 8 N Max. force on gripper jaw Fz static 10 N Max. torque at gripper Mx static 0.1 Nm Max. torque at gripper My static 0.1 Nm Max. torque at gripper Mz static 0.1 Nm Product weight 11 g Type of mounting Clamped Pneumatic connection M3 Note on materials RoHS-compliant Material cover cap POM Material housing Anodised wrought aluminium alloy Material gripper jaws High-alloy steel
More Information
Manufacturer Nr.
HGPM-08-EO-G8
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568160579
Weight
0.105000
HS-Code
84798997
Article authenticity
Original product
Condition of article
New
