Festo 534309. Ball valve VAPB-2-F-25-F05

Name: Festo 534309. Ball valve VAPB-2-F-25-F05
Brand: Festo
SKU: FES-534309
Price: 85.01 EUR
Availability: InStock

€85.01

Excl. 19% VAT , excl. Shipping Cost

Article

FES-534309

Manufacturer Nr.

VAPB-2-F-25-F05

Ball valve

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

Total price

Design	2-way ball valve
Type of actuation	Mechanical
Sealing principle	Soft
Mounting position	optional
Type of mounting	In-line installation
Connection Process valve	Rp2
Switching position indicator	Slot direction = flow direction
Flange hole pattern	F05
Nominal size DN	50
Flow direction	Reversible
Nominal pressure PN	25
Breakaway torque at differential pressure, nominal pressure, process valve PN	29 Nm
Break-away torque at a differential pressure of 1 MPa (10 bar, 145 psi)	22 Nm
Based on standard	ISO 5211
Symbol	00991458
Medium	Compressed air to ISO 8573-1:2010 [-:-:-] Inert gases Water Neutral fluids
Media temperature	-20 °C ... 150 °C
Flow rate Kv	292 m³/h
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364 zone III
Material housing	Brass Nickel-plated
Material number housing	2.0402 CW617N
Material seals	HNBR PTFE
Material ball	Brass Hard-chrome-plated
Material number ball	2.0402 CW617N
Material shaft	Brass
Material number shaft	2.0401 CW614N
Product weight	3100 g
Corrosion resistance class CRC	1 - Low corrosion stress

More Information
Manufacturer Nr.	VAPB-2-F-25-F05
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568086817
Weight	2.700000
HS-Code	84818081
Article authenticity	Original product
Condition of article	New
