Festo 4783598. Ball valve VZBD-11/4-W3-16-T-2-F0405-V14V14

Name: Festo 4783598. Ball valve VZBD-11/4-W3-16-T-2-F0405-V14V14
Brand: Festo
SKU: FES-4783598
Price: 294.87 EUR
Availability: InStock

€294.87

Excl. 19% VAT , excl. Shipping Cost

Article

FES-4783598

Manufacturer: Festo

Manufacturer Nr.

VZBD-11/4-W3-16-T-2-F0405-V14#

Ball valve

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 4783598. Ball valve VZBD-11/4-W3-16-T-2-F0405-V14V14
€294.87
Excl. 19% VAT , excl. Shipping Cost
Festo 1692219. Ball valve VZBA-2"-GGG-63-32L-F0507-V4V4T
€745.01
Excl. 19% VAT , excl. Shipping Cost
Festo 1002558. Angle seat valve VZXF-L-M22C-M-B-N112-350-M1-V4V4T-50-6
€431.08
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Downloads

Design	2-way ball valve
Type of actuation	Mechanical
Sealing principle	Soft
Mounting position	optional
Type of mounting	In-line installation
Connection Process valve	Weld-on end to ISO 1127
Switching position indicator	Slot direction = flow direction
Flange hole pattern	F0405
Inside diameter	38.4 mm
Nominal size DN	32
Valve function	2/2
Flow direction	Reversible
Nominal pressure PN	16
Breakaway torque at differential pressure, nominal pressure, process valve PN	23 Nm
Based on standard	ISO 1127 ISO 5211
Symbol	00991458
Medium	Vapour Compressed air to ISO 8573-1:2010 [-:-:-] Inert gases Water Neutral fluids
Media temperature	-20 °C ... 200 °C
Flow rate Kv	230 m³/h
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364 zone III
Suitable for use with food	See supplementary material information
Material housing	Stainless steel casting
Material number housing	1.4409
Material seat seal	PTFE, modified
Material seals	FPM PTFE
Material ball	Stainless steel casting
Material number ball	1.4409
Material shaft	High-alloy stainless steel
Material number shaft	1.4401
Product weight	2050 g
Approval	3-A sanitary CRN
CE mark (see declaration of conformity)	In accordance with EU Pressure Equipment Directive
Explosion protection	Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)
Corrosion resistance class CRC	4 - Very high corrosion stress

More Information
Manufacturer Nr.	VZBD-11/4-W3-16-T-2-F0405-V14#
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568275280
Weight	2.300000
HS-Code	84818081
Article authenticity	Original product
Condition of article	New
