Festo 192962. connecting cable SIM-K-GD-10-PU
€48.06
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-192962
Manufacturer Nr.
SIM-K-GD-10-PU
connecting cable
Frequently Bought Together
-
This Item:
€48.06Excl. 19% VAT , excl. Shipping Cost
-
Festo 569841. connecting cable NEBU-M12W5-K-10-LE4
€25.96Excl. 19% VAT , excl. Shipping Cost
-
Festo 569842. connecting cable NEBU-M8G3-E-10-LE3
€25.14Excl. 19% VAT , excl. Shipping Cost
Total price
| Conforms to standard | Wire colours and connection numbers to EN 60947-5-2 EN 61076-2-104 EN 61984 |
| Cable designation | Without inscription label holder |
| Frequency of connection | 100 |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Round |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | M8 snap-locking A-coded to EN 61076-2-104 |
| Electrical connection 1, number of connections/cores | 3 |
| Electrical connection 1, used connections/cores | 3 |
| Electrical connection 1, type of mounting | Snap-in locking |
| Electrical connection 1, connection pattern | 00991871 |
| Electrical connection 2, function | Controller side |
| Electrical connection 2, connection type | Cable |
| Electrical connection 2, connector system | Open end |
| Electrical connection 2, number of connections/cores | 3 |
| Electrical connection 2, used connections/cores | 3 |
| Operational voltage range DC | 0 V ... 60 V |
| Operational voltage range AC | 0 V ... 60 V |
| Current rating at 40° C | 3 A |
| Immunity to surge | 1.5 kV |
| Cable length | 10 m |
| Cable characteristic | Standard |
| Test conditions cable | Bending strength: to Festo standard Test conditions on request Energy chain: > 5 million cycles, bending radius 28 mm |
| Bending radius, fixed cable | 23 mm |
| Bending radius, moving cable | 46 mm |
| Cable diameter | 4.5 mm |
| Cable diameter tolerance | ± 0.1 mm |
| Cable structure | 3 x 0.25 mm² |
| Nominal cross section conductor | 0.25 mm² |
| Wire ends | Wire end sleeve |
| Degree of protection | IP65 IP67 |
| Note on degree of protection | In assembled state |
| Ambient temperature | -25 °C ... 70 °C |
| Ambient temperature with moving cable | -5 °C ... 70 °C |
| Storage temperature | -25 °C ... 70 °C |
| CE mark (see declaration of conformity) | To EU Low Voltage Directive In accordance with EU RoHS Directive |
| CE marking (see declaration of conformity) | To UK regulations for electrical equipment To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Note on materials | RoHS-compliant Free of halogen |
| Pollution degree | 3 |
| Corrosion resistance class CRC | 4 - Very high corrosion stress |
| Material cable sheath | TPE-U(PUR) |
| Cable sheath colour | grey |
| Material housing | TPE-U(PUR) |
| Housing colour | Black |
| Material seals | NBR |
| Material electrical contact | Gold-plated brass |
| Material insulating sheath | PP |
| Manufacturer Nr. | SIM-K-GD-10-PU |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568079673 |
| Weight | 0.250000 |
| HS-Code | 85444290 |
| Article authenticity | Original product |
| Condition of article | New |
