Festo 8003130. connecting cable NEBU-M8G4-K-9-LE4
€22.67
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8003130
Manufacturer Nr.
NEBU-M8G4-K-9-LE4
connecting cable
Frequently Bought Together
-
This Item:
€22.67Excl. 19% VAT , excl. Shipping Cost
-
Festo 541338. connecting cable NEBU-M8W3-K-2.5-LE3
€6.85Excl. 19% VAT , excl. Shipping Cost
-
Festo 192963. connecting cable SIM-K-WD-10-PU
€48.06Excl. 19% VAT , excl. Shipping Cost
Total price
| Conforms to standard | Wire colours and connection numbers to EN 60947-5-2 EN 61076-2-104 |
| Explosion protection | The information in the certificate must be observed! Zone 2 (ATEX) Zone 22 (ATEX) |
| Cable designation | With 2x inscription label holders |
| Product weight | 245 g |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Round |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | M8x1, A-coded, to EN 61076-2-104 |
| Electrical connection 1, number of connections/cores | 4 |
| Electrical connection 1, used connections/cores | 4 |
| Electrical connection 1, type of mounting | Screw-type lock |
| Electrical connection 1, connection pattern | 00991872 |
| Electrical connection 2, function | Controller side |
| Electrical connection 2, connection type | Cable |
| Electrical connection 2, connector system | Open end |
| Electrical connection 2, number of connections/cores | 4 |
| Electrical connection 2, used connections/cores | 4 |
| Operational voltage range DC | 0 V ... 30 V |
| Operational voltage range AC | 0 V ... 30 V |
| Current rating at 40° C | 3 A |
| Immunity to surge | 0.8 kV |
| Cable length | 9 m |
| Cable characteristic | Standard |
| Test conditions cable | Bending strength: to Festo standard Test conditions on request Energy chain: > 5 million cycles, bending radius 75 mm |
| Bending radius, fixed cable | 14 mm |
| Bending radius, moving cable | 46 mm |
| Cable diameter | 4.5 mm |
| Cable diameter tolerance | ± 0.1 mm |
| Cable structure | 4 x 0.25 mm² |
| Nominal cross section conductor | 0.25 mm² |
| Degree of protection | IP65 IP68 IP69K |
| Note on degree of protection | In assembled state |
| Special characteristics | Oil resistant |
| Ambient temperature | -25 °C ... 70 °C |
| Ambient temperature with moving cable | -5 °C ... 70 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| CE marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Note on materials | RoHS-compliant Free of halogen Free of phosphoric acid ester |
| Pollution degree | 3 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Material cable sheath | TPE-U(PUR) |
| Cable sheath colour | grey |
| Material housing | TPE-U(PUR) |
| Housing colour | Black |
| Material screw-type lock | Nickel-plated brass |
| Material seals | NBR |
| Material electrical contact | Gold-plated copper alloy |
| Material insulating sheath | PP |
| Manufacturer Nr. | NEBU-M8G4-K-9-LE4 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568062620 |
| Weight | 0.240000 |
| HS-Code | 85444290 |
| Article authenticity | Original product |
| Condition of article | New |
