Precision vacuum regulator G 3/4", -1 to 0,7 bar
€3,071.50
Excl. 19% VAT ,
excl. Shipping Cost
Article
FL-067773
Manufacturer Nr.
RP 34 VU
Precision vacuum regulator G 3/4", -1 to 0,7 bar
Frequently Bought Together
-
This Item:
€3,071.50Excl. 19% VAT , excl. Shipping Cost
-
2/2-way vacuum valve (NC), G 3/8", -0,9 to 2bar, 24 V DC
€234.73Excl. 19% VAT , excl. Shipping Cost
-
Multi stage ejectors to 64% vacuum, G 3/8", to 220 l/min
€202.77Excl. 19% VAT , excl. Shipping Cost
Total price
Application:
These vacuum regulators allow precise pressure regulation in the vacuum and overpressure range. They provide the facility to regulate the vacuum as a bypass or in shut-off technology:
1. Bypass adjustment*: This adjustment should be used, if an existing vacuum must be reduced by delivering compressed air. Recommended for adjusting large vacuum quantities. 2. Stop adjustment*: The vacuum is pulled and adjusted by the regulator. Once the desired value is reached, the regulator is closed. Recommended to save energy.
Materials:
Body: Aluminium die-casting, internal parts: stainless steel/brass, diaphragms: NBR
Temperature range:
-40 to +90 °C
Input pressure:
max. 17 bar
Pressure gauge connection:
G 1/4"
Control accuracy:
± 2.5 mbar
These vacuum regulators allow precise pressure regulation in the vacuum and overpressure range. They provide the facility to regulate the vacuum as a bypass or in shut-off technology:
1. Bypass adjustment*: This adjustment should be used, if an existing vacuum must be reduced by delivering compressed air. Recommended for adjusting large vacuum quantities. 2. Stop adjustment*: The vacuum is pulled and adjusted by the regulator. Once the desired value is reached, the regulator is closed. Recommended to save energy.
Materials:
Body: Aluminium die-casting, internal parts: stainless steel/brass, diaphragms: NBR
Temperature range:
-40 to +90 °C
Input pressure:
max. 17 bar
Pressure gauge connection:
G 1/4"
Control accuracy:
± 2.5 mbar
| Thread | G 3/4" |
| Suction performance [m³/h] | 48,0 |
| Suction performance [l/min] | 800 |
| Pressure gauge connection | G 1/4" |
| Pressure regulation range [bar] | -1 to 0.7 |
| D [mm] | 115 |
| L [mm] | 87 |
| H [mm] | 238 |
| Mounting brackets | RP 34 VU W |
| Manufacturer Nr. | RP 34 VU |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571604394 |
| Weight | 24.000000 |
| HS-Code | 90328100 |
| Article authenticity | Original product |
| Condition of article | New |
