Enerpac EP3404JB, Electric Hydraulic Pump, 3,0 liters Usable Oil, NEMA 5-15 Plug

The Enerpac E-Pulse drives high productivity through its innovative design. Smart controls enable the motor to maintain constant power providing higher flow than traditional pumps. Adjustable speed control enables precision as required. E-Pulse is designed for convenience.

Features include a cord management system and integrated pendant control with a magnet that fits securely into the handle of the pump. The durable aluminum housing is designed to give easy access for serviceability. E-Pulse is the heart to any hydraulic system, ensuring high performance and providing ultimate convenience.

• Two-stage pump with high by-pass pressure:
  2,13 l/min at 175 bar,
  0,52 l/min at 700 bar
• Smart controls enable motor to maintain constant power across the pressure range
• 24VDC power regulator minimizes effects of poor power supply
• Six-piston block design provides even flow for smooth operation of cylinder or tool.

• Durable aluminium housing
• High-efficiency permanent magnet, direct drive motor enables continuous use and long service life
• Built-in thermal protection
• IP Rating: IP54 on the pump, IP67 on the pendant

• Speed control with dial adjustment for precise operation
• Pendant and cord management system
• Convenient oil fill port, oil level indicator and automatic breather.

• Operation, programming and diagnostics status provided to operator with yellow, green, and red LED as well as vibration pulses.
• Fault codes warn operators of any issues related to voltage, temperature, button controls, or if professional service is required.

Dimension imperial

Dimension metric
