Aventics Rodless cylinders, Series RTC-BV R480676504 RTC-DA-050-0540-BV-IBM00S00NLP000P0P0
€1,317.68
Excl. 19% VAT ,
excl. Shipping Cost
Article
AVE-R480676504
Manufacturer Nr.
R480676504
RTC-DA-050-0540-BV-IBM00S00NLP000P0P0
Frequently Bought Together
-
This Item:
€1,317.68Excl. 19% VAT , excl. Shipping Cost
-
Aventics R480963078 SEALING TAPE RTC-80-0600-M
€85.15Excl. 19% VAT , excl. Shipping Cost
-
Aventics Blanking plate 1825503932 SIZE 02
€10.76Excl. 19% VAT , excl. Shipping Cost
Total price
| Piston Ø | 50 mm |
| Stroke | 1371.6 mm |
| Functional principle | Double-acting |
| Magnetic piston | with magnetic piston |
| Guide | integrated guide |
| Version rodless cylinder | Basic Version |
| Piston force | 1237 N |
| Pressure for determining piston forces | 6,3 bar |
| Cushioning length | 20 mm |
| Cushioning energy | 15 J |
| Cushioning | Pneumatically |
| Cushioning | adjustable |
| Speed max. | 3 m/s |
| Stroke max. | 9900 mm |
| Working pressure min. | 2 bar |
| Working pressure max | 8 bar |
| Min. ambient temperature | -10 °C |
| Max. ambient temperature | 60 °C |
| Medium | Compressed air |
| Oil content of compressed air min. | 0 mg/m³ |
| Oil content of compressed air max. | 1 mg/m³ |
| Max. particle size | 5 µm |
| Weight 0 mm stroke | 3.37 kg |
| Weight +10 mm stroke | 0.065 kg |
| Material cylinder tube | Aluminum |
- Oval piston enables higher loads and torques, and highly compact designs
- Comprehensive range with many variants and options enables configurations that are individually tailored to the application
- One-piece slide and piston increase stability
- Minimal leakage and a wide range of speeds thanks to a special internal sealing strip and grease
| Manufacturer Nr. | R480676504 |
|---|---|
| Manufacturer | Aventics |
| GPSR manufacturer information | AVENTICS GmbH, Ulmer Straße 4, DE-30880 Laatzen, aventics.com |
| Weight | 3.370000 |
| HS-Code | 84123100 |
| Article authenticity | Original product |
| Condition of article | New |
