Aventics 5/2-directional valve, Series 581, size 3 5813223100 V581-5/2DS-024DC-I3-2P22-HBX-AA-X-S-T1
€317.58
Excl. 19% VAT ,
excl. Shipping Cost
Article
AVE-5813223100
Manufacturer Nr.
5813223100
V581-5/2DS-024DC-I3-2P22-HBX-AA-X-S-T1
Frequently Bought Together
-
This Item:
€317.58Excl. 19% VAT , excl. Shipping Cost
-
Aventics R480738289 HF04-8-11
€1,552.59Excl. 19% VAT , excl. Shipping Cost
-
Aventics R480663596 SSI-DA-020-0020-4-02-4-023-000-00
€61.93Excl. 19% VAT , excl. Shipping Cost
Total price
| Activation | Electrically |
| Nominal flow Qn | 4800 l/min |
| Switching principle | 5/2, double solenoid |
| Compressed air connection output | Base plate ISO 5599-1 |
| Min. working pressure | -0.95 bar |
| Max. working pressure | 10 bar |
| Operational voltage DC | 24 V |
| Voltage tolerance DC | -10% / +10% |
| Manual override | with detent |
| Electrical connection type | Plug |
| Electrical connection size | Form B, industry |
| Actuating control | Double Solenoid |
| Sealing principle | Soft seal |
| Pilot | External |
| Standards | ISO 5599-1 |
| Pilot valve width | 22 mm |
| Valve type | Spool valve |
| Blocking principle | Single base plate principle |
| Connection type | Plate connection |
| Compressed air connection input | Base plate ISO 5599-1 |
| Compressed air connection, exhaust | Base plate ISO 5599-1 |
| Compressed air connection pilot exhaust | M5 |
| Power consumption DC | 5 W |
| Flow conductance C | 18.9 l/(s*bar) |
| Throttle | with throttle |
- Standardized valve system
- ISO size 1 to 4 available
- Robust design
- Integrated exhaust throttles
- Numerous voltage ranges
- Pressure range up to 16 bar possible
- CNOMO interface
- Small dimensions
- Fast shifting times
- Easy and flexible custom specific configurations via online configurator
| Manufacturer Nr. | 5813223100 |
|---|---|
| Manufacturer | Aventics |
| GPSR manufacturer information | AVENTICS GmbH, Ulmer Straße 4, DE-30880 Laatzen, aventics.com |
| Weight | 1.000000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
Customers Who Bought This Item Also Bought
Aventics R480634321 ITS-DA-200-0010-2-2-1-1-8-000-00-000-BAS
€1,096.49
Excl. 19% VAT ,
excl. Shipping Cost
Aventics Fixed Clevis (MP1 mount) R432015737 TM-3.25-DETACH MP1 MOUNT
