SMC ZH13BSA-08-10. ZH-A, Vacuum Ejector, Box Style/Body Ported Style, Metric
Article
SMC-ZH13BSA-08-10
Manufacturer Nr.
ZH13BSA-08-10
Accessories: W/ Bracket - W/o Silencer (or None in the Case of Box Style)
Nozzle Diameter: 13 (Ø 1.3 mm)
Model: B (Box Style)
Port SUP.: 08 (One-touch Fitting Ø8 mm)
Port EXH.: None
Vacuum Pressure: S [-90 kPa
-89 kPa (Box Style)]:
Port VAC.: 10 (One-touch Fitting Ø10)
Frequently Bought Together
Body ported type/ Box type vacuum ejector. Compact and lightweight
Suction flow rate up to 155 l/min
Nozzle diameters: 0.5, 0.7, 1, 1.3, 1.5, 1.8 and 2 mm
Multiple piping variations: One-touch fittings and screw-in connections (G/Rc/NPT)
4 mounting types: direct, standard bracket, L-bracket or DIN rail.
More Information
Manufacturer Nr.
ZH13BSA-08-10
Manufacturer
SMC
GPSR manufacturer information
SMC Deutschland GmbH Boschring 13-15 DE-63329 Egelsbach www.smc.eu
Weight
0.028000
HS-Code
84141089
Article authenticity
Original product
Condition of article
New
