Festo 8085108. Mini slide DGST-6-40-PA
Manufacturer Nr.
DGST-6-40-PA
Frequently Bought Together
Stroke 40 mm Adjustable end position range/length front 13.1 mm Adjustable end position range/length rear 11.6 mm Piston diameter 6 mm Operating mode, drive unit Yoke Cushioning Elastic cushioning rings/plates at both ends Mounting position optional Guide Recirculating ball bearing guide Design Twin piston
Yoke
Piston rod
Slide Position detection Via proximity switch Symbol 00991249 Operating pressure 0.15 MPa ... 0.8 MPa Operating pressure 1.5 bar ... 8 bar Operating pressure 21.75 psi ... 116 psi Max. speed 0.5 m/s Repetition accuracy <= 0.3 mm Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -10 °C ... 60 °C Impact energy in end positions 0.018 J Cushioning length 0.9 mm Max. force Fy 260 N Max. force Fz 260 N Max. moment Mx 1.2 Nm Max. moment My 1.2 Nm Max. moment Mz 1.2 Nm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 25 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 34 N Moving mass 78 g Product weight 150 g Type of mounting With through-hole Pneumatic connection M3 Note on materials RoHS-compliant Material cover Wrought aluminium alloy Material seals HNBR Material guide POM
TPE-E
High-alloy steel Material housing Wrought aluminium alloy Material piston rod High-alloy stainless steel
More Information
Manufacturer Nr.
DGST-6-40-PA
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568449964
Weight
0.160000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
