Festo 8062806. Guide axis ELFC-KF-45-500
Manufacturer Nr.
ELFC-KF-45-500
Frequently Bought Together
Working stroke 500 mm Size 45 Stroke reserve 0 mm Mounting position optional Guide Recirculating ball bearing guide Design Guidance Symbol 00992984 Max. acceleration 250 m/s² Max. speed 1.5 m/s Duty cycle 100% Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364 zone III Suitability for the production of Li-ion batteries Metals with more than 1% copper, zinc or nickel by mass are excluded from use. Exceptions are nickel in steel, chemically nickel-plated surfaces, printed circuit boards, cables, electrical plug connectors and coils Cleanroom class Class 7 according to ISO 14644-1 Degree of protection IP40 Ambient temperature 0 °C ... 50 °C 2nd moment of area Iy 140000 mm⁴ 2nd moment of area Iz 170000 mm⁴ Max. force Fy 300 N Max. force Fz 600 N Max. moment Mx 5.5 Nm Max. moment My 4.7 Nm Max. moment Mz 4.7 Nm Torsional mass moment of inertia It 8500 mm⁴ Displacement force 4.5 N Fy at theoretical life value of 100 km (only guide consideration) 1104 N Fz at theoretical life value of 100 km (only guide consideration) 2208 N Mx at theoretical life value of 100 km (only guide consideration) 20 Nm My at theoretical life value of 100 km (only guide consideration) 17 Nm Mz at theoretical life value of 100 km (only guide consideration) 17 Nm Moving mass 144 g Additional weight per 10 mm stroke 23 g Material end cap Painted die cast aluminium Material profile Anodised wrought aluminium alloy Note on materials RoHS-compliant Material cover tape High-alloy stainless steel Material cover Painted die-cast aluminium Material guide slide Steel Material guide rail Steel Material slide Die-cast aluminium
More Information
Manufacturer Nr.
ELFC-KF-45-500
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568296353
Weight
1.600000
HS-Code
84821090
Article authenticity
Original product
Condition of article
New
