Festo 4514740. Valve VOFC-LT-M32C-MC-G14-F19
€280.13
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-4514740
Manufacturer Nr.
VOFC-LT-M32C-MC-G14-F19
Valve
Frequently Bought Together
-
This Item:
€280.13Excl. 19% VAT , excl. Shipping Cost
-
Festo 197050. Solenoid valve MHP1-M1H-2/2G-M3-TC
€29.96Excl. 19% VAT , excl. Shipping Cost
-
Festo 196659. Solenoid valve CDVI5.0-MT2H-5JS
€234.81Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 3/2-way, closed, monostable |
| Type of actuation | Electric |
| Construction width | 51 mm |
| Standard nominal flow rate | 703 l/min |
| pneumatic working port | G1/4 |
| Operating pressure | 0.1 MPa ... 0.8 MPa |
| Operating pressure | 1 bar ... 8 bar |
| Design | Piloted piston poppet valve |
| Type of reset | Mechanical spring |
| Degree of protection | IP65 |
| Certificate issuing authority | TÜV 968/V 1251.00/21 |
| Nominal size | 6 mm |
| Sealing principle | Hard |
| Mounting position | optional |
| Manual override | None |
| Type of piloting | Pilot actuated |
| Pilot air supply | External Internal |
| Flow direction | Non-reversible |
| Symbol | 00992275 |
| Safety function | Safe venting |
| Safety Integrity Level (SIL) | Up to SIL 3 High Demand mode To SIL 3 Low Demand mode |
| Note on operating pressure | 0 - 0.8 MPa with ext. pilot air |
| Flow rate Kv pressurisation | 0.64 m³/h |
| Flow rate Kv exhaust | 1.46 m³/h |
| Standard nominal flow rate 2-3 | 1596 l/min |
| Switching time off | 18 ms |
| Switching time on | 24 ms |
| Explosion protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:2:2] |
| Corrosion resistance class CRC | 4 - Very high corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Media temperature | -25 °C ... 60 °C |
| Ambient temperature | -25 °C ... 60 °C |
| Product weight | 550 g |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 3 | G1/4 |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Ematal coated aluminium |
| Manufacturer Nr. | VOFC-LT-M32C-MC-G14-F19 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568274689 |
| Weight | 0.650000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
