Festo 4787544. Adapter NEFV-V12-M12W8-0.6-M12QG5
Manufacturer Nr.
NEFV-V12-M12W8-0.6-M12QG5
Frequently Bought Together
Type of mounting With through-hole Product weight 157 g Electrical connection 1, function Field device side Electrical connection 1, design Round Electrical connection 1, connection type Socket Electrical connection 1, cable outlet Angled Electrical connection 1, connector system M12x1, A-coded to EN 61076-2-101 Electrical connection 1, number of connections/cores 8 Electrical connection 1, used connections/cores 8 Electrical connection 1, type of mounting Screw-type lock Electrical connection 1, connection pattern 00992265 Electrical connection 2, function Analogue output module (green), digital input module (white), analogue input module (yellow), digital output module (red)
Controller side Electrical connection 2, design Round Electrical connection 2, connection type 4x plug connectors Electrical connection 2, cable outlet Straight Electrical connection 2, connector system M12x1, A-coded to EN 61076-2-101 electrical connection 2, type of mounting Screw-type lock Operational voltage range DC 0 V ... 30 V Nominal operating voltage DC 24 V Operating voltage DC load voltage 0 V ... 30 V Nominal DC operating voltage, load voltage 24 V Current rating at 40° C 2 A Immunity to surge 0.06 kV Cable length 0.623 m Cable characteristic Standard Test conditions cable Test conditions on request Degree of protection IP65
IP67 Note on degree of protection In assembled state Ambient temperature -25 °C ... 80 °C Ambient temperature with moving cable -5 °C ... 80 °C LABS (PWIS) conformity VDMA24364-B1/B2-L Note on materials RoHS-compliant Pollution degree 3 Corrosion resistance class CRC 2 - Moderate corrosion stress Material cable sheath TPE-U(PUR) Cable sheath colour grey Material housing TPE-U(PUR) Housing colour Black Material union nut Nickel-plated die-cast zinc Material electrical contact Brass
Nickel-plated Material insulating sheath PP
More Information
Manufacturer Nr.
NEFV-V12-M12W8-0.6-M12QG5
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568275327
Weight
0.170000
HS-Code
85444290
Article authenticity
Original product
Condition of article
New
