Festo 3488206. Hand lever valve VHER-H-B43E-G18
Manufacturer Nr.
VHER-H-B43E-G18
Frequently Bought Together
Valve function 4/3 exhausted Type of actuation Manual Construction width 51 mm Standard nominal flow rate 600 l/min pneumatic working port G1/8 Operating pressure 0 bar ... 10 bar Note on operating pressure Vacuum operation at connection 3 only
In the case of dual-pressure operation, the pressure at port 1 must be higher than at port 3. Design Rotary gate valve Nominal size 6 mm Exhaust-air function With flow control option Instructions on use Actuate manually only Sealing principle Hard Type of piloting Direct Flow direction Non-reversible Symbol 00995941 Freedom from overlap yes Switching position indicator With accessories Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature -20 °C ... 80 °C Ambient temperature -20 °C ... 80 °C Actuating torque 0.9 Nm Product weight 260 g Type of mounting Either:
Front panel mounting
With through-hole Pneumatic connection, port 1 G1/8 Pneumatic connection, port 2 G1/8 Pneumatic connection, port 3 G1/8 Pneumatic connection, port 4 G1/8 Note on materials RoHS-compliant Material seals NBR Material housing Die-cast aluminium Material lever Die-cast aluminium
More Information
Manufacturer Nr.
VHER-H-B43E-G18
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568269876
Weight
0.290000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
