Festo 8022582. electric drive ESBF-BS-40-200-16P
Manufacturer Nr.
ESBF-BS-40-200-16P
Frequently Bought Together
Size 40 Stroke 200 mm Piston rod thread M12x1.25 Reversing backlash theoretical 40 µm Spindle diameter 16 mm Spindle pitch 16 mm/U Torsional backlash at piston rod +/- 0.2 deg Based on standard ISO 15552 Mounting position optional Piston-rod end Male thread Type of motor Stepper motor
Servo motor Position detection Via proximity switch Design Electric cylinder with ball screw Spindle type Ball screw Symbol 00991941 Protection against torque/guide With plain-bearing guide Max. acceleration 25 m/s² Max. speed 1.33 m/s Repetition accuracy ±0.01 mm Duty cycle 100% Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364 zone III Storage temperature -20 °C ... 60 °C Suitable for use with food See supplementary material information Relative air humidity 0 - 95% Degree of protection IP40 Ambient temperature 0 °C ... 60 °C Max. drive torque 7.7 Nm Max. radial force at drive shaft 130 N Max. feed force Fx 3000 N Frictional torque independent of load 0.2 Nm Reference value effective load, horizontal 300 kg Reference value effective load, vertical 300 kg Mass moment of inertia JH per metre of stroke 0.5225 kgcm² Mass moment of inertia JL per kg of working load 0.06485 kgcm² Mass moment of inertia JO 0.1249 kgcm² Moving mass for 0 mm stroke 467 g Additional moving mass per 10 mm stroke 26 g Basic weight for 0 mm stroke 1237 g Additional weight per 10 mm stroke 47 g Type of mounting Via female thread
Or accessories Interface code, actuator D40 Note on materials RoHS-compliant Material cover Wrought aluminium alloy, smooth anodised Material piston rod High-alloy stainless steel Material screws Galvanised steel Material spindle nut Rolled steel Material spindle Rolled steel Material cylinder barrel Smooth-anodised wrought aluminium alloy
More Information
Manufacturer Nr.
ESBF-BS-40-200-16P
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568278373
Weight
2.100000
HS-Code
84799070
Article authenticity
Original product
Condition of article
New
