Festo SPAU-V1R-H-G18FD-L-PNLK-PNVBA# (8001223) Pressure Sensor
€126.16
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8001223
Manufacturer Nr.
SPAU-V1R-H-G18FD-L-PNLK-PNVBA#
Pressure Sensor
Frequently Bought Together
-
This Item:
€126.16Excl. 19% VAT , excl. Shipping Cost
-
Festo 150218. Mounting plate APL-2N-VPEV
€31.04Excl. 19% VAT , excl. Shipping Cost
-
Festo 8022752. Pressure sensor SPAW-P6R-G12M-2P-M12
€240.30Excl. 19% VAT , excl. Shipping Cost
Total price
| Permission | RCM mark c UL us - Listed (OL) |
| CE certificate (see declaration of conformity) | acc. to EU-EMV Directive acc. to EU-RoHS Directive |
| KC-mark | KC-EMV |
| Material information | RoHs compliant |
| Measured parameter | Relative pressure |
| Measurement process | Piezoresistive pressure sensor |
| Pressure measurement range starting value [bar] | 0 |
| Pressure measurement range end value [bar] | -1 |
| Overload range [bar] | 5 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| Information about operating and control medium | Oiled operation possible |
| Medium temperature [°C] | 0 to 50 |
| ambient temperature [°C] | 0 to 50 |
| Resolution analogue-digital converter [Bit] | 12 |
| Accuracy FS [%FS] | 1,5 |
| Repeatability in ± %FS [%FS] | 0,3 |
| Temperature coefficient in ± %FS/K [%FS/K] | 0,05 |
| Control output | 2 x PNP or 2 x NPN switchable |
| Switch function | Freely programmable |
| Switching element function | Opener/closer switchable |
| Max. output current [mA] | 100 |
| Analogue output | 0 - 10 V 4 - 20 mA 1 - 5 V |
| Rise time [ms] | 3 |
| Max. load resistance current output [Ohm] | 500 |
| Min. load resistance voltage output [kOhm] | 10 |
| Short circuit resistance | yes |
| Report | IO-Link |
| IO-Link, report | Device V 1.1 |
| IO-Link, profile | Smart sensor profile |
| IO-Link, function classes | Teach channel Diagnosis Identification Binary data channel (BDC) Process data variables (PDV) |
| IO-Link, communication mode | COM2 (38.4 kBaud) |
| IO-Link, SIO mode support | yes |
| IO-Link, port type | A |
| IO-Link, process data width OUT | 0 Bytes |
| IO-Link, process data width IN | 2 Bytes |
| IO-Link, process data contents IN | 14 bit PDV (pressure measurement) 2 bit BDC (pressure monitoring) |
| IO-Link, minimum cycle time | 3 ms |
| IO-Link, data memory needed [Byte] | 500 |
| Operating voltage range DC [V] | 20 to 30 |
| Reverse polarity protection | for all electrical connections |
| Electrical connection 1, connection type | Plug |
| Electrical connection 1, connection technology | M8x1 A coded to EN 61076-2-104 |
| Electrical connection 1, number of pins / wires | 4 |
| Fastening type | With Slot rail |
| installation position | arbitrary |
| Pneumatic connection | G1/8 |
| Product weight [g] | 70 |
| Display type | Illuminating LCD |
| Presentable unit(s) | MPa Bar inchH2O inch Hg kPa kgf/cm² mmHg psi |
| Setting options | IO-Link Teach-In über Display und Tasten |
| Tamper-proof fuse | IO-Link PIN code |
| Settings range threshold value [%] | 0 to 100 |
| Settings range hysteresis [%] | 0 to 90 |
| Protection category | IP65 IP67 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Manufacturer Nr. | SPAU-V1R-H-G18FD-L-PNLK-PNVBA# |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568277000 |
| Weight | 0.085000 |
| HS-Code | 90262020 |
| Article authenticity | Original product |
| Condition of article | New |
