Festo 575522. Pneumatic valve VUWS-L25-B52-G14
Manufacturer Nr.
VUWS-L25-B52-G14
Frequently Bought Together
Valve function 5/2 double solenoid Type of actuation Pneumatic Valve size 26.5 mm Standard nominal flow rate 1300 l/min pneumatic working port G1/4 Operating pressure -0.09 MPa ... 1 MPa Operating pressure -0.9 bar ... 10 bar Design Piston gate valve Approval c UL us - Recognized (OL) Nominal size 6.9 mm Exhaust-air function With flow control option Sealing principle Soft Mounting position optional Manual override None Type of piloting Direct Pilot air supply Internal Flow direction Reversible Symbol 00991037 lap Positive overlap Pilot pressure 0.15 MPa ... 1 MPa Pilot pressure 1.5 bar ... 10 bar Switching time reversal 10 ms Explosion protection The information in the certificate must be observed!
Zone 1 (ATEX)
Zone 2 (ATEX)
Zone 21 (ATEX)
Zone 22 (ATEX) Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Vibration resistance Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 Shock resistance Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature -10 °C ... 60 °C Pilot medium Compressed air to ISO 8573-1:2010 [7:4:4] Ambient temperature -10 °C ... 60 °C Product weight 363 g Type of mounting Either:
On manifold rail
With through-hole Breather connection Not ducted Pilot air port 12 M5 Pilot air port 14 M5 Pneumatic connection, port 1 G1/4 Pneumatic connection, port 2 G1/4 Pneumatic connection, port 3 G1/4 Pneumatic connection, port 4 G1/4 Pneumatic connection, port 5 G1/4 Note on materials RoHS-compliant Material seals HNBR
NBR Material housing Die-cast aluminium
Painted Material piston slide Wrought aluminium alloy Material screws Galvanised steel
More Information
Manufacturer Nr.
VUWS-L25-B52-G14
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568260798
Weight
0.370000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
