Festo 575259. Solenoid valve VUVS-L20-M32C-MZD-G18-F7
€48.53
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-575259
Manufacturer Nr.
VUVS-L20-M32C-MZD-G18-F7
Solenoid valve
Frequently Bought Together
-
This Item:
€48.53Excl. 19% VAT , excl. Shipping Cost
-
Festo 575613. Solenoid valve VUVS-L30-B52-D-G38-F8-1B2
€100.85Excl. 19% VAT , excl. Shipping Cost
-
Festo 8036719. Solenoid valve VUVS-LT30-T32H-MZD-G38-F8-1B2
€114.62Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 3/2-way, closed, monostable |
| Type of actuation | Electric |
| Valve size | 21 mm |
| Standard nominal flow rate | 700 l/min |
| pneumatic working port | G1/8 |
| Operating pressure | -0.09 MPa ... 1 MPa |
| Operating pressure | -0.9 bar ... 10 bar |
| Design | Piston gate valve |
| Type of reset | Mechanical spring |
| Approval | c UL us - Recognized (OL) |
| Nominal size | 5.7 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | External |
| Flow direction | Reversible |
| Symbol | 00995995 |
| lap | Positive overlap |
| Pilot pressure | 0.25 MPa ... 1 MPa |
| Pilot pressure | 2.5 bar ... 10 bar |
| b value | 0.35 |
| C value | 2.9 l/sbar |
| Switching time off | 32 ms |
| Switching time on | 14 ms |
| Max. positive test pulse with 0 signal | 1900 µs |
| Max. negative test pulse with 1 signal | 2700 µs |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -10 °C ... 60 °C |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -10 °C ... 60 °C |
| Product weight | 136 g |
| Type of mounting | Either: On manifold rail With through-hole |
| Breather connection | Not ducted |
| Pilot exhaust port 82 | M5 |
| Pilot air port 12 | M5 |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Die-cast aluminium Painted |
| Material piston slide | Wrought aluminium alloy |
| Material screws | Galvanised steel |
| Manufacturer Nr. | VUVS-L20-M32C-MZD-G18-F7 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568103705 |
| Weight | 0.160000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
