Festo 575257. Solenoid valve VUVS-L20-M32C-AZD-G18-F7
Manufacturer Nr.
VUVS-L20-M32C-AZD-G18-F7
Frequently Bought Together
Valve function 3/2-way, closed, monostable Type of actuation Electric Valve size 21 mm Standard nominal flow rate 700 l/min pneumatic working port G1/8 Operating pressure -0.09 MPa ... 1 MPa Operating pressure -0.9 bar ... 10 bar Design Piston gate valve Type of reset Pneumatic spring Approval c UL us - Recognized (OL) Nominal size 5.7 mm Exhaust-air function With flow control option Sealing principle Soft Mounting position optional Manual override Detenting
Non-detenting Type of piloting Pilot actuated Pilot air supply External Flow direction Reversible Symbol 00991406 lap Positive overlap Pilot pressure 0.25 MPa ... 1 MPa Pilot pressure 2.5 bar ... 10 bar b value 0.35 C value 2.9 l/sbar Switching time off 21 ms Switching time on 14 ms Max. positive test pulse with 0 signal 1900 µs Max. negative test pulse with 1 signal 2700 µs Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Vibration resistance Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 Shock resistance Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature -10 °C ... 60 °C Pilot medium Compressed air to ISO 8573-1:2010 [7:4:4] Ambient temperature -10 °C ... 60 °C Product weight 138 g Type of mounting Either:
On manifold rail
With through-hole Breather connection Not ducted Pilot exhaust port 82 M5 Pilot air port 12 M5 Pneumatic connection, port 1 G1/8 Pneumatic connection, port 2 G1/8 Pneumatic connection, port 3 G1/8 Note on materials RoHS-compliant Material seals HNBR
NBR Material housing Die-cast aluminium
Painted Material piston slide Wrought aluminium alloy Material screws Galvanised steel
More Information
Manufacturer Nr.
VUVS-L20-M32C-AZD-G18-F7
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568103682
Weight
0.160000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
