Festo 539292. Rotary distributor GF-1/2-1/4

Name: Festo 539292. Rotary distributor GF-1/2-1/4
Brand: Festo
SKU: FES-539292
Price: 221.58 EUR
Availability: InStock

€221.58

Excl. 19% VAT , excl. Shipping Cost

Article

FES-539292

Manufacturer Nr.

GF-1/2-1/4

Rotary distributor

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 539292. Rotary distributor GF-1/2-1/4
€221.58
Excl. 19% VAT , excl. Shipping Cost
Festo 186243. Multiple distributor QSLV4-G1/8-4
€10.75
Excl. 19% VAT , excl. Shipping Cost
Festo 153215. Multiple distributor QSLV2-1/4-8
€9.66
Excl. 19% VAT , excl. Shipping Cost

Total price

Nominal size	15 mm
Mounting position	optional
Operating pressure complete temperature range	-0.095 MPa ... 1 MPa
Operating pressure complete temperature range	-0.95 bar ... 10 bar
Operating pressure complete temperature range	-13.775 psi ... 145 psi
Standard flow rate 1-2.1 (6->0)	4050 l/min
Standard flow rate 1-2.X open (6->0)	14130 l/min
Max. rotational speed	2500 rpm
Operating medium	Compressed air to ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free)
Note on operating and pilot medium	Use 5 µm filter when operating with water Lubricated operation possible
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-10 °C ... 80 °C
Max. tightening torque	8 Nm
Nominal torque	4.25 Nm
Tolerance for nominal tightening torque	± 20%
Pneumatic connection, port 1	G1/2
Pneumatic connection, port 2	G1/4
Note on materials	RoHS-compliant

More Information
Manufacturer Nr.	GF-1/2-1/4
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568177461
Weight	1.400000
HS-Code	84798997
Article authenticity	Original product
Condition of article	New
