Festo 1366257. Fitting NPCK-C-D-G18-K6

Name: Festo 1366257. Fitting NPCK-C-D-G18-K6
Brand: Festo
SKU: FES-1366257
Price: 13.98 EUR
Availability: InStock

€13.98

Excl. 19% VAT , excl. Shipping Cost

Article

FES-1366257

Manufacturer: Festo

Manufacturer Nr.

NPCK-C-D-G18-K6

Fitting

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 1366257. Fitting NPCK-C-D-G18-K6
€13.98
Excl. 19% VAT , excl. Shipping Cost
Festo 7605. Barbed tubing connector RTU-PK-6/6
€1.59
Excl. 19% VAT , excl. Shipping Cost
Festo 9388. Bulkhead quick connector SCK-PK-4-KU
€4.17
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Downloads

Nominal size	2.9 mm
Type of seal on screwed plug	Sealing ring
Mounting position	optional
Design	Straight design
Operating pressure complete temperature range	-0.095 MPa ... 1.2 MPa
Operating pressure complete temperature range	-0.95 bar ... 12 bar
Operating pressure complete temperature range	-13.775 psi ... 174 psi
Note on operating pressure	Water: max. 0.6 MPa at 0 - 85 °C Water vapour: 0 – 0.15 MPa, 0 – 1.5 bar, 0 – 22 psi
Operating medium	Compressed air to ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) Water vapour
Note on operating and pilot medium	Lubricated operation possible
Corrosion resistance class CRC	4 - Very high corrosion stress
LABS (PWIS) conformity	VDMA24364-B2-L
Suitability for the production of Li-ion batteries	Metals with more than 1% copper, zinc or nickel by mass are excluded from use. Exceptions are nickel in steel, chemically nickel-plated surfaces, printed circuit boards, cables, electrical plug connectors and coils
Suitable for use with food	See supplementary material information
Note on temperature of medium	Water vapour: max. 120 °C
Degree of protection	IP69K
Ambient temperature	-20 °C ... 120 °C
Note on ambient temperature	The NPCK can be used from -40 to 60 °C when using suitable tubing and observing the maximum operating pressure of the tube.
Nominal torque	6.5 Nm
Note on the nominal tightening torque	4 Nm +/-10% for NPCK to MPA-C
Tolerance for nominal tightening torque	± 10%
Product weight	14.1 g
Pneumatic connection, port 1	Male thread G1/8
Pneumatic connection, port 2	For tubing outside diameter of 6 mm
Material union nut	High-alloy stainless steel
Material screwed plug	High-alloy stainless steel
Note on materials	RoHS-compliant
Material sealing ring	PEEK

More Information
Manufacturer Nr.	NPCK-C-D-G18-K6
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568061869
Weight	0.016000
HS-Code	73072910
Article authenticity	Original product
Condition of article	New
