Festo 8022777. Pressure sensor SPAW-B11R-G14F-2PA-M12
Manufacturer Nr.
SPAW-B11R-G14F-2PA-M12
Frequently Bought Together
Symbol 00991159 Approval RCM trademark
c UL us listed (OL) CE mark (see declaration of conformity) To EU EMC Directive
In accordance with EU RoHS Directive CE marking (see declaration of conformity) To UK instructions for EMC
To UK RoHS instructions Note on materials RoHS-compliant Measured variable Relative pressure Measurement method Metal thin-film pressure sensor Start value for pressure measuring range -0.1 MPa Start value for pressure measuring range -1 bar Start value for pressure measuring range -14.5 psi End value for pressure measuring range 1 MPa End value for pressure measuring range 10 bar End value for pressure measuring range 145 psi Overload pressure 2 MPa Overload pressure 20 bar Overload pressure 290 psi Operating medium Compressed air to ISO 8573-1:2010 [-:-:-]
Liquid media
Gaseous media Media temperature -20 °C ... 85 °C Ambient temperature 0 °C ... 80 °C Accuracy in ± % FS 1 %FS Repetition accuracy in ± %FS 0.15 %FS Switching output 2xPNP Switching function Freely programmable Switching element function Switchable Max. output current 250 mA Analogue output 4 - 20 mA Rise time 3 ms Short circuit current rating yes Operational voltage range DC 15 V ... 35 V Reverse polarity protection For operating voltage Electrical connection 1, connection type Plugs Electrical connection 1, connector system M12x1, A-coded to EN 61076-2-101 Electrical connection 1, number of connections/cores 5 Electrical connection 1, type of mounting Screw-type lock Electrical connection 1, connection pattern 00995383 Type of mounting Via female thread
With accessories Mounting position optional Pneumatic connection Female thread G1/4 Product weight 230 g Material housing ABS
High-alloy stainless steel Material in contact with the medium High-alloy stainless steel Display type 4-place alphanumeric
LED indicator Displayable units MPa
bar
kPa
kg/cm²
psi Switching status indication Red LED Setting options Via display and keys Protection against tampering PIN code Setting range threshold value 0.5 % ... 100 % Setting range hysteresis 0.5 % ... 99.5 % Degree of protection IP65
IP67 Corrosion resistance class CRC 4 - Very high corrosion stress LABS (PWIS) conformity VDMA24364 zone III
More Information
Manufacturer Nr.
SPAW-B11R-G14F-2PA-M12
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568257781
Weight
0.300000
HS-Code
90262020
Article authenticity
Original product
Condition of article
New
