Festo 578257. Blanking plug NPQH-P-S4-P10
€1.02
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-578257
Manufacturer Nr.
NPQH-P-S4-P10
Blanking plug
Festo 578257. Blanking plug NPQH-P-S4-P10 is available to buy in increments of 10
Frequently Bought Together
-
This Item:
€1.02Excl. 19% VAT , excl. Shipping Cost
-
Festo 578314. Connector NPQH-D-S14-Q8-P10
€6.59Excl. 19% VAT , excl. Shipping Cost
-
Festo 578388. Push-in T-connector NPQH-T-Q10-Q8-P10
€6.15Excl. 19% VAT , excl. Shipping Cost
Total price
| Size | Standard |
| Mounting position | optional |
| Design | Blanking plug |
| Size of pack | 10 |
| Symbol | 00997424 |
| Operating pressure complete temperature range | -0.095 MPa ... 2 MPa |
| Operating pressure complete temperature range | -0.95 bar ... 20 bar |
| Operating pressure complete temperature range | -13.775 psi ... 290 psi |
| Note on operating pressure | Water: max. 0.6 MPa at 0 - 50 °C |
| Certificate issuing authority | NSF C0523185 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Suitable for use with food | See declaration of conformity NSF/ANSI 169 |
| Ambient temperature | 0 °C ... 150 °C |
| Product weight | 2.3 g |
| Pneumatic connection, port 1 | Push-in sleeve Ø 4 mm |
| Note on materials | RoHS-compliant |
| Material housing | Brass, chemically nickel-plated |
| Manufacturer Nr. | NPQH-P-S4-P10 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568059606 |
| Weight | 0.002700 |
| HS-Code | 74122000 |
| Article authenticity | Original product |
| Condition of article | New |
