Festo 561031. Sub-base VMPAL-AP-14-QS1/4"-1-T1
€30.96
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-561031
Manufacturer Nr.
VMPAL-AP-14-QS1/4"-1-T1
Sub-base
Frequently Bought Together
-
This Item:
€30.96Excl. 19% VAT , excl. Shipping Cost
-
Festo 539227. Channel separation VABD-S6-1-P1-C
€9.10Excl. 19% VAT , excl. Shipping Cost
-
Festo 561021. Sub-base VMPAL-AP-20-QS8-1-T1
€33.54Excl. 19% VAT , excl. Shipping Cost
Total price
| Width | 14.9 mm |
| Length | 107.3 mm |
| Grid dimension | 14.9 mm |
| Valve size | 14 mm |
| Pressure-zone division | Duct 1 |
| Max. number of valve positions | 1 |
| Flow direction | Reversible |
| Valve terminal structure | Valve sizes can be mixed |
| Max. number of valve coils | 1 |
| Operating pressure | -0.09 MPa ... 1 MPa |
| Operating pressure | -0.9 bar ... 10 bar |
| Pilot pressure | 0.3 MPa ... 0.8 MPa |
| Pilot pressure | 3 bar ... 8 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 51.35 g |
| Pneumatic connection, port 2 | For tubing outside diameter of 1/4" |
| Pneumatic connection, port 4 | For tubing O.D. 1/4" |
| Note on materials | RoHS-compliant |
| Material sub-base | PA-reinforced |
| Manufacturer Nr. | VMPAL-AP-14-QS1/4"-1-T1 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568098919 |
| Weight | 0.100000 |
| HS-Code | 84819000 |
| Article authenticity | Original product |
| Condition of article | New |
