Festo 561008. Sub-base VMPAL-AP-14-QS1/4"-2

Name: Festo 561008. Sub-base VMPAL-AP-14-QS1/4"-2
Brand: Festo
SKU: FES-561008
Price: 33.95 EUR
Availability: InStock

€33.95

Excl. 19% VAT , excl. Shipping Cost

Article

FES-561008

Manufacturer Nr.

VMPAL-AP-14-QS1/4"-2

Sub-base

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 561008. Sub-base VMPAL-AP-14-QS1/4"-2
€33.95
Excl. 19% VAT , excl. Shipping Cost
Festo 538808. Multi-pin CPV10-VI-P4-M7-C
€104.08
Excl. 19% VAT , excl. Shipping Cost
Festo 527577. Air supply plate CPVSC1-SP-P
€77.53
Excl. 19% VAT , excl. Shipping Cost

Total price

Width	14.9 mm
Length	107.3 mm
Grid dimension	14.9 mm
Valve size	14 mm
Max. number of valve positions	1
Flow direction	Reversible
Valve terminal structure	Valve sizes can be mixed
Max. number of valve coils	2
Operating pressure	-0.09 MPa ... 1 MPa
Operating pressure	-0.9 bar ... 10 bar
Pilot pressure	0.3 MPa ... 0.8 MPa
Pilot pressure	3 bar ... 8 bar
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	3 - high corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-5 °C ... 50 °C
Product weight	51.05 g
Pneumatic connection, port 2	For tubing outside diameter of 1/4"
Pneumatic connection, port 4	For tubing O.D. 1/4"
Note on materials	RoHS-compliant
Material sub-base	PA-reinforced

More Information
Manufacturer Nr.	VMPAL-AP-14-QS1/4"-2
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568098681
Weight	0.070000
HS-Code	84819000
Article authenticity	Original product
Condition of article	New
