Festo 574586. Multi-pin plug distributor NEDU-L4R1-M8G3L-M12G8
Manufacturer Nr.
NEDU-L4R1-M8G3L-M12G8
Multi-pin plug distributor
Frequently Bought Together
Width 24 mm Height 23 mm Length 87 mm Ready status indication Green LED Status indication Yellow LED Mounting position optional Product weight 58 g Electrical connection 1 Straight socket, M8, 3-pin Electrical connection 2 Straight plug connector, M12x1, 8-pin Operational voltage range DC 10 V ... 30 V Current rating at 40° C 3 A Max. current per plug-in position 2 A Degree of protection IP68 Ambient temperature -20 °C ... 80 °C LABS (PWIS) conformity VDMA24364 zone III Note on materials RoHS-compliant Corrosion resistance class CRC 3 - high corrosion stress Material housing PBT-reinforced Housing colour grey Material seals FPM Material electrical contact Nickel-plated and gold-plated Material socket Nickel-plated brass
More Information
Manufacturer Nr.
NEDU-L4R1-M8G3L-M12G8
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568103446
Weight
0.060000
HS-Code
85366990
Article authenticity
Original product
Condition of article
New
