Festo 1804962. ISO cylinder DSBC-125-160-PPVA-N3
Manufacturer Nr.
DSBC-125-160-PPVA-N3
Frequently Bought Together
Stroke 160 mm Piston diameter 125 mm Piston rod thread M27x2 Cushioning Pneumatic cushioning, adjustable at both ends Mounting position optional Conforms to standard ISO 15552 Piston-rod end Male thread Design Piston
Piston rod
Profile barrel Position detection Via proximity switch Symbol 00991235 Variants Piston rod at one end Operating pressure 0.02 MPa ... 1 MPa Operating pressure 0.2 bar ... 10 bar Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -20 °C ... 80 °C Impact energy in end positions 3.3 J Cushioning length 45 mm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 6881 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 7363 N Moving mass for 0 mm stroke 2245 g Additional moving mass per 10 mm stroke 63 g Basic weight for 0 mm stroke 6611 g Additional weight per 10 mm stroke 151 g Type of mounting Either:
Via female thread
With accessories Pneumatic connection G1/2 Note on materials RoHS-compliant Material cover Die-cast aluminium, coated Material piston seal TPE-U(PU) Material piston Wrought aluminium alloy Material piston rod High-alloy steel Material piston rod wiper TPE-U(PU) Buffer seal material TPE-U(PU) Cushioning piston material POM Material cylinder barrel Smooth-anodised wrought aluminium alloy Material nut Galvanised steel Material bearing POM Material collar screws Galvanised steel
More Information
Manufacturer Nr.
DSBC-125-160-PPVA-N3
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568248796
Weight
9.000000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
