Festo DAPS-0960-090-RS1-F14-MW (8005066) Semi-Rotary Drive

Name: Festo DAPS-0960-090-RS1-F14-MW (8005066) Semi-Rotary Drive
Brand: Festo
SKU: FES-8005066
Price: 3272.54 EUR
Availability: InStock

€3,272.54

Excl. 19% VAT , excl. Shipping Cost

Article

FES-8005066

Manufacturer:

Manufacturer Nr.

DAPS-0960-090-RS1-F14-MW

Semi-Rotary Drive

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo DAPS-0960-090-RS1-F14-MW (8005066) Semi-Rotary Drive
€3,272.54
Excl. 19% VAT , excl. Shipping Cost
Festo 533431. Semi-rotary drive DAPS-0030-090-RS1-F04
€238.66
Excl. 19% VAT , excl. Shipping Cost
Festo 552875. Semi-rotary drive DAPS-0015-090-RS1-F03-CR
€486.22
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Downloads

Position drive dimensions	0960
Flange drilling screen	F14
Swivel angle [deg]	92
Shaft connection Depth [mm]	48,5
Standard connection to fitting	ISO 5211
Dampening	No dampening
installation position	arbitrary
Principle of operation	single action
Construction set up	Joch kinematics
Position detection	without
Closing direction	Right closing
Valve connection corresponds to standard	VDI/VDE 3845 (NAMUR)
Safety Integrity Level (SIL)	Product can be used in SRP/CS up to SIL 2 Low Demand Product can be used in SRP/CS up to SIL 2 High Demand
Operating pressure [bar]	2.8 to 8.4
Nominal operating pressure [bar]	5,6
CE certificate (see declaration of conformity)	to EU EX protection directive (ATEX)
ATEX gas category	II 2G
ATEX dust category	II 2D
Ex ignition protection type gas	Ex h IIC T6...T3 Gb X
Ex ignition protection type dust	Ex h IIIC T85°C...T200°C Db X
Ex ambient temperature	-50°C <= Ta <= +60°C
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	2 - moderate corrosion stress
ambient temperature [°C]	-20 to 80
Air consumption a 6 bar per cycle 0°-90°-0° [LTR]	41,30
Product weight [g]	50.600
Shaft connection	T46
Pneumatic connection	G1/4
Material information	RoHs compliant
Cover material	Aluminium wrought alloy
Seals material	FKM NBR PUR
Housing material	Aluminium wrought alloy
Screws material	High-alloyed steel
Shaft material	High-alloyed steel
Material number shaft	1.4305
Information about the adjustment range of the end positions	Selectively one end position is adjustable
Connection pressure for spring strength [bar]	2,8
Spring force torque at a swivel angle 0° [Nm]	320,0
Spring force torque at a swivel angle 50° [Nm]	240,0
Spring force torque at 90° [Nm]	480,0
Spring strength	1

More Information
Manufacturer Nr.	DAPS-0960-090-RS1-F14-MW
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568257156
Weight	0.100000
HS-Code	84123900
Article authenticity	Original product
Condition of article	New
