Festo DAPS-2880-090-R-F16-T6 (553188) Semi-Rotary Drive
€4,272.17
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-553188
Manufacturer Nr.
DAPS-2880-090-R-F16-T6
Semi-Rotary Drive
Frequently Bought Together
-
This Item:
€4,272.17Excl. 19% VAT , excl. Shipping Cost
-
Festo 8048016. Semi-rotary drive DFPD-20-RP-90-RS30-F05-R3-EP
€123.07Excl. 19% VAT , excl. Shipping Cost
-
Festo 8030619. Semi-rotary drive DAPS-0120-090-RS4-F0710-T4
€517.21Excl. 19% VAT , excl. Shipping Cost
Total price
| Position drive dimensions | 2880 |
| Flange drilling screen | F16 |
| Swivel angle [deg] | 90 |
| Adjustable range end position at 0° [deg] | -5 to 5 |
| Shaft connection Depth [mm] | 49,5 |
| Standard connection to fitting | ISO 5211 |
| Dampening | No dampening |
| installation position | arbitrary |
| Principle of operation | double acting |
| Construction set up | Joch kinematics |
| Position detection | without |
| Closing direction | Right closing |
| Valve connection corresponds to standard | VDI/VDE 3845 (NAMUR) |
| Safety Integrity Level (SIL) | Product can be used in SRP/CS up to SIL 2 Low Demand Product can be used in SRP/CS up to SIL 2 High Demand |
| Operating pressure [bar] | 3 to 8.4 |
| Nominal operating pressure [bar] | 5,6 |
| CE certificate (see declaration of conformity) | to EU EX protection directive (ATEX) |
| ATEX gas category | II 2G |
| ATEX dust category | II 2D |
| Ex ignition protection type gas | Ex h IIC T6...T3 Gb X |
| Ex ignition protection type dust | Ex h IIIC T85°C...T200°C Db X |
| Ex ambient temperature | -50°C <= Ta <= +60°C |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 3 - severe corrosion stress |
| ambient temperature [°C] | -50 to 60 |
| Rotary torque for nominal operating pressure and 0° pivot angle [Nm] | 2.880,0 |
| Rotary torque for nominal operating pressure and 50° pivot angle [Nm] | 1.440,0 |
| Rotary torque for nominal operating pressure and 90° pivot angle [Nm] | 2.160,0 |
| Information about torque | The operating torque of the actuator may not be higher than the maximum permitted torque listed in ISO 5211, related to the size of the fastening flange and the coupling. |
| Air consumption a 6 bar per cycle 0°-90°-0° [LTR] | 140,00 |
| Product weight [g] | 56.000 |
| Shaft connection | T46 |
| Pneumatic connection | G3/8 |
| Material information | LABS containing materials included RoHs compliant |
| Cover material | Aluminium wrought alloy |
| Seals material | FVMQ PTFE reinforced |
| Housing material | Aluminium wrought alloy |
| Screws material | High-alloyed steel |
| Shaft material | High-alloyed steel |
| Material number shaft | 1.4305 |
| Adjustable range end position at 90° [deg] | 85 to 95 |
| Manufacturer Nr. | DAPS-2880-090-R-F16-T6 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568195663 |
| Weight | 0.100000 |
| HS-Code | 84123900 |
| Article authenticity | Original product |
| Condition of article | New |
