Festo 1002550. Angle seat valve VZXF-L-M22C-M-B-N1-240-M1-V4V4T-50-10

Name: Festo 1002550. Angle seat valve VZXF-L-M22C-M-B-N1-240-M1-V4V4T-50-10
Brand: Festo
SKU: FES-1002550
Price: 246.84 EUR
Availability: InStock

€246.84

Excl. 19% VAT , excl. Shipping Cost

Article

FES-1002550

Manufacturer: Festo

Manufacturer Nr.

VZXF-L-M22C-M-B-N1-240-M1-V4V#

Angle seat valve

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 1002550. Angle seat valve VZXF-L-M22C-M-B-N1-240-M1-V4V4T-50-10
€246.84
Excl. 19% VAT , excl. Shipping Cost
Festo 4405651. Ball valve VZBM-11/4-RP-25-D-2-F03-B2B3
€43.60
Excl. 19% VAT , excl. Shipping Cost
Festo 8060544. Angle seat valve VZXA-B-TS7-1"-M2-V14T-8.3-K-46-17-V4
€291.54
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Downloads

Design	Poppet valve with piston drive
Type of actuation	Pneumatic
Sealing principle	Soft
Mounting position	optional
Type of mounting	In-line installation
Line connection	Threaded coupling 1 NPT to ANSI/ASME B 1.20.1
Nominal size	24 mm
Valve function	2/2-way, closed, monostable
Flow direction	Non-reversible
Medium pressure	0 MPa ... 1 MPa
Medium pressure	0 bar ... 10 bar
Nominal pressure PN	40
Exhaust-air function	Without flow control option
Type of reset	Mechanical spring
Type of piloting	Externally controlled
Pneumatic connection	Female thread G1/8
Operating pressure	0.6 MPa ... 1 MPa
Operating pressure	6 bar ... 10 bar
Operating pressure	87 psi ... 145 psi
Symbol	00991367
Medium	Vapour Mineral oil-based hydraulic fluid Inert gases Mineral oil Water Filtered compressed air, grade of filtration 200 µm Neutral fluids
Direction of flow	Below valve seat, for gaseous and liquid media
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Max. viscosity	600 mm²/s
Media temperature	-40 °C ... 200 °C
Ambient temperature	-10 °C ... 60 °C
Flow rate Kv	11 m³/h
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364 zone III
Material process valve housing	Stainless steel casting
Material number process valve housing	1.4408
Material spindle seal	PTFE
Material seat seal	PTFE
Product weight	1600 g
Corrosion resistance class CRC	3 - high corrosion stress
Material drive housing	High-alloy stainless steel

More Information
Manufacturer Nr.	VZXF-L-M22C-M-B-N1-240-M1-V4V#
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568226527
Weight	1.900000
HS-Code	84818073
Article authenticity	Original product
Condition of article	New
