Festo 562027. Plug NECU-S-M12G3-HX
Manufacturer Nr.
NECU-S-M12G3-HX
Frequently Bought Together
Based on standard EN 61076-2-101
EN 61984 Approval c UL us - Recognized (OL) Frequency of connection 3 Product weight 17.5 g Electrical connection 3-pin
A-coded
M12x1
Straight plug/insulation displacement connector Operational voltage range DC 0 V ... 32 V Operational voltage range AC 0 V ... 32 V Current rating at 40° C 4 A Immunity to surge 0.8 kV Permissible cable diameter 2.9 mm ... 5.1 mm Individual wire diameter 0.1 mm Wire diameter 0.9 mm ... 1.6 mm Connection cross section 0.14 mm² ... 0.34 mm² Degree of protection IP65
IP67 Ambient temperature -25 °C ... 85 °C LABS (PWIS) conformity VDMA24364-B2-L Note on materials RoHS-compliant Pollution degree 3 Corrosion resistance class CRC 1 - Low corrosion stress Material housing PA
Die-cast zinc
Nickel-plated Material screw-type lock Die-cast zinc, nickel-plated Material seals FPM
PUR Material electrical contact Bronze Permissible insulating sheath PP
PVC
TPE-E
More Information
Manufacturer Nr.
NECU-S-M12G3-HX
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568056667
Weight
0.021000
HS-Code
85366990
Article authenticity
Original product
Condition of article
New
