Festo 557917. Hinge cylinder DW-80-125-Y-AB
Manufacturer Nr.
DW-80-125-Y-AB
Frequently Bought Together
Stroke 125 mm Piston diameter 80 mm Piston rod thread M20x1.5 Broad rod clevis/swivel mounting 28 mm Cushioning Pneumatic cushioning, adjustable at both ends Mounting position optional Design Piston
Piston rod with rod clevis
Swivel mounting on bearing cap
Cylinder barrel Speed regulation Integrated flow control at both ends Position detection Via proximity switch Piston-rod end Male thread with rod clevis Operating pressure 1 bar ... 10 bar Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Ambient temperature -10 °C ... 60 °C Impact energy in end positions 1.8 J Cushioning length 30 mm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 2721 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 3016 N Moving mass for 0 mm stroke 1651 g Additional moving mass per 10 mm stroke 39 g Basic weight for 0 mm stroke 4185 g Additional weight per 10 mm stroke 65 g alternative connections See product drawing Type of mounting Via swivel mounting on bearing cap
With accessories Pneumatic connection Rc3/8 Material rod clevis Cast steel
Tempered steel Note on materials RoHS-compliant Material wiper Bronze Material cover Die-cast aluminium
Anodised Material seals NBR Material piston rod Tempered steel
Hard-chrome-plated Material cylinder barrel Wrought aluminium alloy
Anodised
More Information
Manufacturer Nr.
DW-80-125-Y-AB
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568204174
Weight
4.000000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
