Festo 1369112. Semi-rotary drive DSM-25-270-HD-A-B
Manufacturer Nr.
DSM-25-270-HD-A-B
Frequently Bought Together
Size 25 Swivel angle 0 deg ... 270 deg Mounting position optional Mode of operation Double-acting Design Vane Position detection Via proximity switch Symbol 00991265 Operating pressure 0.2 MPa ... 1 MPa Operating pressure 2 bar ... 10 bar Max. swivel frequency at 0.6 MPa (6 bar, 87 psi) 1.5 Hz Operating medium Compressed air to ISO 8573-1:2010 [7:-:-] Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -10 °C ... 60 °C Max. axial force 350 N Max. radial force 450 N Theoretical torque at 0.6 MPa (6 bar, 87 psi) 5 Nm Product weight 950 g Type of mounting Via female thread Pneumatic connection M5 Note on materials RoHS-compliant Material drive shaft Steel
Nickel-plated Material seals TPE-U(PU) Material housing Wrought aluminium alloy
More Information
Manufacturer Nr.
DSM-25-270-HD-A-B
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568231163
Weight
1.000000
HS-Code
84123900
Article authenticity
Original product
Condition of article
New
