Festo 570186. Mini slide DGSL-12-150-EA
Manufacturer Nr.
DGSL-12-150-EA
Frequently Bought Together
Stroke 150 mm Adjustable end position range/length front 67 mm Adjustable end position range/length rear 5.5 mm Piston diameter 16 mm Operating mode, drive unit Yoke Cushioning Short elastic cushioning rings/pads at both ends Mounting position optional Guide Ball bearing cage guide Design Yoke
Piston
Piston rod
Slide Position detection Via proximity switch Symbol 00991263 Operating pressure 0.1 MPa ... 0.8 MPa Operating pressure 1 bar ... 8 bar Max. speed 0.8 m/s Repetition accuracy 0.3 mm Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature 0 °C ... 60 °C Impact energy in end positions 0.25 J Cushioning length 1 mm Max. force Fy 1400 N Max. force Fz 1400 N Max. moment Mx 20 Nm Max. moment My 15 Nm Max. moment Mz 15 Nm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 104 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 121 N Moving mass 614 g Product weight 1524 g alternative connections See product drawing Type of mounting With through-hole Pneumatic connection M5 Note on materials RoHS-compliant Material cover Wrought aluminium alloy Material seals HNBR Material housing Wrought aluminium alloy Material piston rod High-alloy stainless steel
More Information
Manufacturer Nr.
DGSL-12-150-EA
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568216818
Weight
1.600000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
