Festo 569793. Mini slide DGSC-6-10-P-L
Manufacturer Nr.
DGSC-6-10-P-L
Frequently Bought Together
Stroke 10 mm Piston diameter 6 mm Operating mode, drive unit Yoke Cushioning Elastic cushioning rings/plates at both ends Mounting position optional Guide Ball bearing cage guide Design Scotch yoke system Position detection Without Symbol 00991263 Operating pressure 0.1 MPa ... 0.6 MPa Operating pressure 1 bar ... 6 bar Operating pressure 14.5 psi ... 87 psi Repetition accuracy 0.2 mm Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Ambient temperature 10 °C ... 50 °C Max. force Fy 20 N Max. force Fz 20 N Max. moment Mx 0.3 Nm Max. moment My 0.4 Nm Max. moment Mz 0.4 Nm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 12.7 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 17 N Moving mass 17 g Product weight 42 g Type of mounting Via female thread and dowel pin Pneumatic connection M3 Note on materials RoHS-compliant Material cover POM Material seals NBR Material guide High-alloy steel Material housing High-alloy stainless steel Material piston rod High-alloy stainless steel
More Information
Manufacturer Nr.
DGSC-6-10-P-L
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568216450
Weight
0.060000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
