Festo 574038. Compact cylinder ADNGF-40-60-PPS-A

Name: Festo 574038. Compact cylinder ADNGF-40-60-PPS-A
Brand: Festo
SKU: FES-574038
Price: 151.72 EUR
Availability: InStock

€151.72

Excl. 19% VAT , excl. Shipping Cost

Article

FES-574038

Manufacturer Nr.

ADNGF-40-60-PPS-A

Compact cylinder

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 574038. Compact cylinder ADNGF-40-60-PPS-A
€151.72
Excl. 19% VAT , excl. Shipping Cost
Festo 574041. Compact cylinder ADNGF-50-15-PPS-A
€162.81
Excl. 19% VAT , excl. Shipping Cost
Festo 577214. Compact cylinder ADNGF-20-50-PPS-A
€91.43
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke	60 mm
Piston diameter	40 mm
Based on standard	ISO 21287
Cushioning	Self-adjusting pneumatic end-position cushioning
Mounting position	optional
Design	Piston Piston rod Profile barrel
Position detection	Via proximity switch
Protection against torque/guide	Guide rod with yoke
Operating pressure	0.14 MPa ... 1 MPa
Operating pressure	1.4 bar ... 10 bar
Mode of operation	Double-acting
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20 °C ... 80 °C
Impact energy in end positions	1.7 J
Cushioning length	5 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke	686 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke	754 N
Moving mass for 0 mm stroke	164 g
Additional moving mass per 10 mm stroke	17 g
Basic weight for 0 mm stroke	430 g
Additional weight per 10 mm stroke	45 g
Pneumatic connection	G1/8
Note on materials	RoHS-compliant
Material collar screws	Steel
Material cover	Anodised wrought aluminium alloy
Material seals	TPE-U(PUR)
Material end plate	Anodised wrought aluminium alloy
Material piston rod	High-alloy steel
Material cylinder barrel	Smooth-anodised wrought aluminium alloy

More Information
Manufacturer Nr.	ADNGF-40-60-PPS-A
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568221614
Weight	0.700000
HS-Code	84123100
Article authenticity	Original product
Condition of article	New
