Festo 572735. Compact cylinder ADN-80-80-A-PPS-A
€161.68
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-572735
Manufacturer Nr.
ADN-80-80-A-PPS-A
Compact cylinder
Frequently Bought Together
-
This Item:
€161.68Excl. 19% VAT , excl. Shipping Cost
-
Festo 536385. Compact cylinder ADN-100-15-I-P-A
€152.15Excl. 19% VAT , excl. Shipping Cost
-
Festo 572729. Compact cylinder ADN-80-20-A-PPS-A
€135.86Excl. 19% VAT , excl. Shipping Cost
Total price
| Stroke | 80 mm |
| Piston diameter | 80 mm |
| Piston rod thread | M16x1.5 |
| Cushioning | Self-adjusting pneumatic end-position cushioning |
| Mounting position | optional |
| Conforms to standard | ISO 21287 |
| Piston-rod end | Male thread |
| Position detection | Via proximity switch |
| Symbol | 00992970 |
| Variants | Piston rod at one end |
| Operating pressure | 0.1 MPa ... 1 MPa |
| Operating pressure | 1 bar ... 10 bar |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20 °C ... 80 °C |
| Impact energy in end positions | 8 J |
| Cushioning length | 7.5 mm |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 2827 N |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 3016 N |
| Moving mass for 0 mm stroke | 400 g |
| Additional moving mass per 10 mm stroke | 25 g |
| Basic weight for 0 mm stroke | 1121 g |
| Additional weight per 10 mm stroke | 79 g |
| Type of mounting | Either: With through-hole Via female thread With accessories |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material collar screws | Steel |
| Material cover | Die-cast aluminium, coated |
| Material seals | TPE-U(PUR) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
| Manufacturer Nr. | ADN-80-80-A-PPS-A |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568219567 |
| Weight | 1.700000 |
| HS-Code | 84123100 |
| Article authenticity | Original product |
| Condition of article | New |
