Festo 560702. Solenoid valve VOVG-L12-M52Q-AH-M5-1H3
€84.03
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-560702
Manufacturer Nr.
VOVG-L12-M52Q-AH-M5-1H3
Solenoid valve
Frequently Bought Together
-
This Item:
€84.03Excl. 19% VAT , excl. Shipping Cost
-
Festo 567792. Solenoid valve MHJ9-HF/LP
€44.07Excl. 19% VAT , excl. Shipping Cost
-
Festo 197043. Solenoid valve MHA1-M5H-2/2G-0,9-PI
€28.19Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Construction width | 25 mm |
| Standard nominal flow rate | 200 l/min |
| pneumatic working port | M5 |
| Operating voltage | 24V DC |
| Operating pressure | 0.2 MPa ... 0.8 MPa |
| Operating pressure | 2 bar ... 8 bar |
| Operating pressure | 29 psi ... 116 psi |
| Design | Piston gate valve |
| Type of reset | Pneumatic spring |
| Degree of protection | IP40 |
| Nominal size | 2.1 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Flow direction | Non-reversible |
| Symbol | 00991049 |
| lap | Positive overlap |
| Switching time off | 18 ms |
| Switching time on | 15 ms |
| Characteristic coil data | 24 V DC: 1.0 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Media temperature | -5 °C ... 50 °C |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -5 °C ... 50 °C |
| Electrical connection | 2-pin Plugs |
| Pneumatic connection, port 1 | M7 |
| Pneumatic connection, port 2 | M5 |
| Pneumatic connection, port 3 | M5 |
| Note on materials | RoHS-compliant |
| Material seals | FPM HNBR NBR |
| Material housing | Wrought aluminium alloy |
| Manufacturer Nr. | VOVG-L12-M52Q-AH-M5-1H3 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568207533 |
| Weight | 0.055000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
