Festo 567466. Pressure sensor SDE5-D10-NF-Q6-V-M8
Manufacturer Nr.
SDE5-D10-NF-Q6-V-M8
Frequently Bought Together
Symbol 00991967 Approval RCM trademark
c UL us - Recognized (OL) CE mark (see declaration of conformity) To EU EMC Directive
In accordance with EU RoHS Directive CE marking (see declaration of conformity) To UK instructions for EMC
To UK RoHS instructions Note on materials RoHS-compliant Measured variable Relative pressure Measurement method Piezoresistive pressure sensor Start value for pressure measuring range 0 bar End value for pressure measuring range 10 bar Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible Media temperature 0 °C ... 50 °C Ambient temperature 0 °C ... 50 °C Repetition accuracy in ± %FS 0.3 %FS Temperature coefficient in ± %FS/K 0.05 %FS/K Analogue output 0 - 10 V Output characteristic curve start value 0 V Output characteristic curve end value 10 V Accuracy analogue output in ± %FS 3 %FS Linearity error in ± %FS 0.3 %FS Short circuit current rating yes Operational voltage range DC 15 V ... 30 V Reverse polarity protection For all electrical connections Electrical connection 3-pin
M8x1
Plugs
To EN 60947-5-2
Round design Type of mounting With accessories Mounting position optional Pneumatic connection QS-6 Product weight 19 g Material housing PA
POM Ready status indication Green LED Degree of protection IP40 Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L
More Information
Manufacturer Nr.
SDE5-D10-NF-Q6-V-M8
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568215415
Weight
0.046000
HS-Code
90262020
Article authenticity
Original product
Condition of article
New
