Festo 563365. Vacuum valve MHA1-2X2/2G-1,5
€87.28
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-563365
Manufacturer Nr.
MHA1-2X2/2G-1,5
Vacuum valve
Frequently Bought Together
-
This Item:
€87.28Excl. 19% VAT , excl. Shipping Cost
-
Festo 556380. Solenoid valve CDVI5.0-MT2H-1X2OLS-EXT
€192.49Excl. 19% VAT , excl. Shipping Cost
-
Festo 567793. Solenoid valve MHJ9-QS-6-HF/LP
€51.40Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 2x2/2-way, monostable, closed |
| Type of actuation | Electric |
| Construction width | 20 mm |
| Standard nominal flow rate | 30 l/min |
| pneumatic working port | Prepared for QSP10 |
| Operating voltage | 24V DC |
| Operating pressure | 0 bar ... 1.5 bar |
| Type of reset | Mechanical spring |
| Degree of protection | IP40 |
| CE mark (see declaration of conformity) | To EU EMC Directive In accordance with EU RoHS Directive |
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions |
| Nominal size | 1.5 mm |
| Grid dimension | 20 mm |
| Exhaust-air function | Without flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Non-detenting |
| Type of piloting | Direct |
| Flow direction | Non-reversible |
| Symbol | 00992254 |
| Signal status display | LED |
| Operating pressure, reversible | -0.95 bar ... 0 bar |
| Suitability for vacuum | yes |
| Standard flow rate | 30 l/min |
| Max. switching frequency | 10 Hz |
| Switching time off | 6 ms |
| Switching time on | 6 ms |
| Duty cycle | 100% |
| Characteristic coil data | 24 V DC: low-current phase 0.7 W, high-current phase 3.0 W |
| Permissible voltage fluctuations | +/- 10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -20 °C ... 60 °C |
| Media temperature | -5 °C ... 50 °C |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 26.3 g |
| Max. cable length | 30 m |
| Electrical connection | Plug KMH |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | Prepared for QSP10 |
| Pneumatic connection, port 11 | Prepared for QSP10 |
| Pneumatic connection, port 2 | Prepared for QSP10 |
| Note on materials | RoHS-compliant |
| Material seals | FPM HNBR NBR |
| Material housing | PA-reinforced PPS reinforced |
| Material screws | Steel |
| Manufacturer Nr. | MHA1-2X2/2G-1,5 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568210786 |
| Weight | 0.037000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
