Festo 547343. Solenoid valve CPVSC1-M4H-J-T-Q3
Manufacturer Nr.
CPVSC1-M4H-J-T-Q3
Frequently Bought Together
Valve function 5/2 double solenoid Type of actuation Electric Valve size 10 mm Standard nominal flow rate 170 l/min pneumatic working port QS-3 Operating voltage 5V DC Operating pressure -0.09 MPa ... 0.7 MPa Operating pressure -0.9 bar ... 7 bar Design Piston gate valve Approval c UL us - Recognized (OL) Degree of protection IP40 Exhaust-air function Without flow control option Sealing principle Soft Mounting position optional Manual override Non-detenting Type of piloting Pilot actuated Pilot air supply External Flow direction Non-reversible Symbol 00992801 lap Positive overlap Pilot pressure 0.3 MPa ... 0.7 MPa Pilot pressure 3 bar ... 7 bar Switching time reversal 8 ms Max. positive test pulse with 0 signal 500 µs Max. negative test pulse with 1 signal 400 µs Characteristic coil data 5 V DC: 1.0 W Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Vibration resistance Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 Shock resistance Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Media temperature -5 °C ... 50 °C Ambient temperature -5 °C ... 50 °C Product weight 56.5 g Electrical connection 2-pin
Plugs Type of mounting With through-hole Pilot exhaust port 82/84 Common line Pneumatic connection, port 1 Common line Pneumatic connection, port 2 QS-3 Pneumatic connection 3/5 combined Common line Pneumatic connection, port 4 QS-3 Note on materials RoHS-compliant Material seals NBR Material housing Die-cast aluminium
More Information
Manufacturer Nr.
CPVSC1-M4H-J-T-Q3
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568188337
Weight
0.100000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
