Festo 547338. Solenoid valve CPVSC1-M4H-J-T-M5
€162.95
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-547338
Manufacturer Nr.
CPVSC1-M4H-J-T-M5
Solenoid valve
Frequently Bought Together
-
This Item:
€162.95Excl. 19% VAT , excl. Shipping Cost
-
Festo 537957. Solenoid valve VMPA2-M1H-K-PI
€113.63Excl. 19% VAT , excl. Shipping Cost
-
Festo 578810. Solenoid valve VMPA14-M1HF-X-PI
€89.62Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 5/2 double solenoid |
| Type of actuation | Electric |
| Valve size | 10 mm |
| Standard nominal flow rate | 170 l/min |
| pneumatic working port | M5 |
| Operating voltage | 5V DC |
| Operating pressure | -0.09 MPa ... 0.7 MPa |
| Operating pressure | -0.9 bar ... 7 bar |
| Design | Piston gate valve |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP40 |
| Exhaust-air function | Without flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | External |
| Flow direction | Non-reversible |
| Symbol | 00992801 |
| lap | Positive overlap |
| Pilot pressure | 0.3 MPa ... 0.7 MPa |
| Pilot pressure | 3 bar ... 7 bar |
| Switching time reversal | 8 ms |
| Max. positive test pulse with 0 signal | 500 µs |
| Max. negative test pulse with 1 signal | 400 µs |
| Characteristic coil data | 5 V DC: 1.0 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Media temperature | -5 °C ... 50 °C |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 56.5 g |
| Electrical connection | 2-pin Plugs |
| Type of mounting | With through-hole |
| Pilot exhaust port 82/84 | Common line |
| Pneumatic connection, port 1 | Common line |
| Pneumatic connection, port 2 | M5 |
| Pneumatic connection 3/5 combined | Common line |
| Pneumatic connection, port 4 | M5 |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
| Manufacturer Nr. | CPVSC1-M4H-J-T-M5 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568188283 |
| Weight | 0.070000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
